DRAGON MINI LASER
DG 6040
Brochure
RUIDA CONTROLLER
WORKING SIZE:
600*400*200MM
LASER POWER:
60W / 80W
ELECTRIC UP & DOWN
WORKTABLE,
RED DOT POINTER
TECHNICAL PARAMETERS
| Effective Working Area | X=600mm, Y=400mm, Z=100mm |
| Laser Power | 60W / 80W |
| Worktable | Electric Up/Down Worktable |
| Red Dot Pointer | With |
| Computer System | WINDOWS XP / Win7 / Win8 |
| Machine Color | Optional |
| Min Shaping Character | Character 2x2mm, Letter 1x1mm |
| Voltage Input | AC220V 60Hz |
| Max Engraving Speed | 1000mm/s |
| Max Cutting Speed | 600mm/s |
| Data Transfer | USB2.0 transmission |
| Control System | Ruida / Corel Controller |
| Graphic Format Supported | AI, PLT, DXF, BMP, DWG, LAS, DXP |
| Compatible Software | Corel Draw, AutoCAD, Illustrator, etc. |
| Water Protecting Sensor | Yes |
| Water Thermometer | Yes |
| Package Weight | 120KG |
| Package Size | 1130 × 800 × 770mm |
